12" Inch Extra Heavy Duty Caster Wheel 3307 pounds Swivel and Upper Brake Cast iron polyurethane Top Plate

12" Inch Caster Wheel 3307 pounds Swivel and Upper Brake Cast iron polyurethane Top Plate

Item Name= VXB009C300BFSB

Extra Heavy Duty

Wheel Diameter= 300mm

Wheel Width= 75mm

Wheel Diameter= 12" Inch = 300mm

Overall Height= 365mm

Overall Height Inch= 14.370"

Mounting Type= Top Plate

Top Plate Size= 200mm x 153mm Top Plate: 14mm+housing: 10mm

Hole distance= 160mm x 90mm

Wheel Core= Cast iron polyurethane

Tire= Cast iron polyurethane

Bearing type= Precision double ball bearing

Load Capacity= 3307 lb

Mounting= Swivel and Upper Brake

Temperature Range= -40 to 180 F

Utilizing VXB009C300BFSB makes it feasible to pull and push items instead of transport And rolling on wheel that has 300mm diameter/11.811" inch. Dimensions of the caster wheel is 75mm (2.953" inch). The Caster with the wheel from end to end is 365mm = 14.370" inch. Mounted via a Top Plate that has the size of 200mm x 153mm Top Plate: 14mm+housing: 10mm and the holes distance of 160mm x 90mm. The Precision double ball bearing design will enable the Cast iron polyurethane tire to roll easily with a core made of Cast iron polyurethane. Maximum load calpacity that should not be exceeded on each wheel, remember to add safety factor, when calculating the load capacity 3307 lb with a Swivel and Upper Brake type. Temperature range is -40 to 180 F. Very important notice, you need to buy the VXB009C300BFSB in order to get one :).
