4" Inch Caster Wheel 88 pounds Fixed Polyvinyl Chloride Top Plate

4" Inch Caster Wheel 88 pounds Fixed Polyvinyl Chloride Top Plate

Item Name= VXB007100PVCF

Wheel Diameter= 100mm

Wheel Width= 27mm

Wheel Diameter= 4" Inch = 100mm

Overall Height= 130mm

Overall Height Inch= 5.118"

Mounting Type= Top Plate

Top Plate Size= 76mm x 76mm

Hole distance= 57mm x 57mm

Wheel Core= Polyvinyl Chloride

Tire= Polyvinyl Chloride

Bearing type= Plain bearing

Load Capacity= 88 lb

Mounting= Fixed

Temperature Range= -40 to 180 F

Mounting VXB007100PVCF is the Low cost solution of making a project to move around by pushing or pulling. And rolling on wheel that has 100mm diameter/3.937" inch. The thickness of the wheel is 27mm or 1.063" inch. The caster dimensions heightwise is 130mm/5.118" inch. Top Plate is the method of installing the caster to your equipment, here are the dimensions 76mm x 76mm with the holes distance of 57mm x 57mm. Low drag was achieved by a Polyvinyl Chloride core on a Polyvinyl Chloride tire spinning freely with a Plain bearing. Bearing in mind that every caster wheel has the load capacity of 88 lb with a Fixed type. The caster temperature range = -40 to 180 F. Buy our VXB007100PVCF, we wish all the best.
