4" Inch Heavy Duty Caster Wheel 441 pounds Fixed Thermoplastic Rubber Top Plate

4" Inch Caster Wheel 441 pounds Fixed Thermoplastic Rubber Top Plate

Item Name= VXB005100BTPRB1

Heavy Duty

Wheel Diameter= 100mm

Wheel Width= 50mm

Wheel Diameter= 4" Inch = 100mm

Overall Height= 142mm

Overall Height Inch= 5.591"

Mounting Type= Top Plate

Top Plate Size= 100mm x 115mm

Hole distance= 75mm x 85mm

Wheel Core= Thermoplastic Rubber

Tire= Thermoplastic Rubber

Bearing type= Double ball beaing

Load Capacity= 441 lb

Mounting= Fixed

Temperature Range= -40 to 180 F

Moves large items quicker using the VXB005100BTPRB1. And rolling on wheel that has 100mm diameter/3.937" inch. The thickness of the wheel is 50mm or 1.969" inch. The caster dimensions heightwise is 142mm/5.591" inch. This wheel caster can be mounted using a Top Plate with the dimensions of 100mm x 115mm and holes distance of 75mm x 85mm. The Double ball beaing design will enable the Thermoplastic Rubber tire to roll easily with a core made of Thermoplastic Rubber. Maximum load calpacity that should not be exceeded on each wheel, remember to add safety factor, when calculating the load capacity 441 lb with a Fixed type. The caster temperature range = -40 to 180 F. Very important notice, you need to buy the VXB005100BTPRB1 in order to get one :).
