4" Inch Heavy Duty Caster Wheel 441 pounds Swivel Cast iron Top Plate

4" Inch Caster Wheel 441 pounds Swivel Cast iron Top Plate

Item Name= VXB005100C

Heavy Duty

Wheel Diameter= 100mm

Wheel Width= 50mm

Wheel Diameter= 4" Inch = 100mm

Overall Height= 142mm

Overall Height Inch= 5.591"

Mounting Type= Top Plate

Top Plate Size= 100mm x 115mm

Hole distance= 75mm x 85mm

Wheel Core= Cast iron

Tire= Cast iron

Bearing type= Roller bearing

Load Capacity= 441 lb

Mounting= Swivel

Temperature Range= -40 to 180 F

Heavy weight capability and Durability made the wheel casters like the VXB005100C a must use, get your do it yourself object move around. Diameter size of the caster wheel has a metric standard 100mm which is equal to 3.937" inch with imperial units. The thickness of the wheel is 50mm or 1.969" inch. The caster dimensions heightwise is 142mm/5.591" inch. Top Plate is the method of installing the caster to your equipment, here are the dimensions 100mm x 115mm with the holes distance of 75mm x 85mm. The Roller bearing design will enable the Cast iron tire to roll easily with a core made of Cast iron. Each caster will carry the load of 441 lb and is Swivel type. The caster temperature range = -40 to 180 F. Very important notice, you need to buy the VXB005100C in order to get one :).
