4" Inch Heavy Duty Caster Wheel 772 pounds Swivel and Upper Brake Aluminium and Polyurethane Top Plate

4" Inch Caster Wheel 772 pounds Swivel and Upper Brake Aluminium and Polyurethane Top Plate

Item Name= VXB005C100BAPUB3

Heavy Duty

Wheel Diameter= 100mm

Wheel Width= 50mm

Wheel Diameter= 4" Inch = 100mm

Overall Height= 150mm

Overall Height Inch= 5.906"

Mounting Type= Top Plate

Top Plate Size= 115mm x 100mm x 6mm

Hole distance= 72mm x 85mm

Wheel Core= Aluminium and Polyurethane

Tire= Aluminium and Polyurethane

Bearing type= Double ball beaing

Load Capacity= 772 lb

Mounting= Swivel and Upper Brake

Temperature Range= -40 to 180 F

VXB005C100BAPUB3 is a device comprising a wheel that's connected to the base of a huge object like a trailers, your home furniture, even your truck to transfer the item more quickly and readily. them.You need {Item Name} to have your office desk, equipment or even a machine to easily roll them around. And rolling on wheel that has 100mm diameter/3.937" inch. The thickness of the wheel is 50mm or 1.969" inch. Overall height of the wheel caster is 150mm = 5.906" inch. Mounted via a Top Plate that has the size of 115mm x 100mm x 6mm and the holes distance of 72mm x 85mm. The weehl core material is Aluminium and Polyurethane and has a Aluminium and Polyurethane tire with a low friction Double ball beaing. Maximum load calpacity that should not be exceeded on each wheel, remember to add safety factor, when calculating the load capacity 772 lb with a Swivel and Upper Brake type. Environment temperature range is -40 to 180 F. Buy our VXB005C100BAPUB3, we wish all the best.
