8" Inch Heavy Duty Caster Wheel 661 pounds Fixed Thermoplastic Rubber Top Plate

8" Inch Caster Wheel 661 pounds Fixed Thermoplastic Rubber Top Plate

Item Name= VXB005200BTPRB1

Heavy Duty

Wheel Diameter= 200mm

Wheel Width= 50mm

Wheel Diameter= 8" Inch = 200mm

Overall Height= 240mm

Overall Height Inch= 9.449"

Mounting Type= Top Plate

Top Plate Size= 100mm x 115mm

Hole distance= 75mm x 85mm

Wheel Core= Thermoplastic Rubber

Tire= Thermoplastic Rubber

Bearing type= Double ball beaing

Load Capacity= 661 lb

Mounting= Fixed

Temperature Range= -40 to 180 F

Heavy weight capability and Durability made the wheel casters like the VXB005200BTPRB1 a must use, get your do it yourself object move around. And rolling on wheel that has 200mm diameter/7.874" inch. Dimensions of the caster wheel is 50mm (1.969" inch). Overall height of the wheel caster is 240mm = 9.449" inch. Mounted via a Top Plate that has the size of 100mm x 115mm and the holes distance of 75mm x 85mm. Low drag was achieved by a Thermoplastic Rubber core on a Thermoplastic Rubber tire spinning freely with a Double ball beaing. Maximum load calpacity that should not be exceeded on each wheel, remember to add safety factor, when calculating the load capacity 661 lb with a Fixed type. Temperature range is -40 to 180 F. Buy the VXB005200BTPRB1 now, just add the quantity to basket and click on Checkout.
